Landing Page Practicum Multi-agent Systems

Agent-based modeling using Netlogo and Python

Authors

Affiliation

Wim Pouw (www.wimpouw.com)

Department of Cognitive Science and AI, Tilburg University, Netherlands

Travis Wiltshire

Department of Cognitive Science and AI, Tilburg University, Netherlands

Overview

Welcome to the landing page for the for the Practicum Multi-agent Systems 2025-2026. Every time the practicum starts you can keep this page open as a reference.

While the lectures focus on the theoretical background of multi-agent systems and gaining a better understanding how simple principles can percolate into complex behavior, the practicals focus on getting you ready to setting up your own data-generating agent based model.

Programming language of choice

We will use Netlogo and Python for this course. Most textbooks and high-quality learning materials teach agent-based modeling using Netlogo. Netlogo was designed to be an intuitive language to learn and reads almost as pseudocode. For this course we will however learn to build our own agent-based models using python, specifically we will make use of PyPi package Mesa (Kazil, Masad, and Crooks 2020). Why? Well you know why! Python is becoming a standard language in the field of computer science and cognitive science, and you already have some familiarity with this language through previous programming course(s). It is good to learn more languages, but it is empowering to know one language well. Since you probably will be using python most during your studies, we have made the decision to have for each netlogo model a python version. We will run and refer the netlogo models as well, as our reference for translating things to python.

Note that if you prefer to use Netlogo for your group project, you are free to do so.

Additional Resources

We have a limited amount of time in this course. Therefore, we will not cover all the details of Netlogo and Mesa. But throughout this document we provide you with resources to learn further, help debug, and explore Netlogo and Mesa models. Sick of reading? Or need inspiration for your group project? Go to the inspiration section for lectures and podcasts that we enjoyed ourselves on these topics, and for a selection of recent publications where state-of-the art agent-based modeling is employed.

• Mesa API documentation: Mesa API
• Mesa overview: Tutorial
• Mesa video tutorials by Zak Jost: Swarm Intelligence and Agent Based Modeling
• Mesa core example model library
• Netlogo getting started tutorials
  • Tutorial #1: Models,
  • Tutorial #2: Commands
  • Tutorial #3: Procedures
• Netlogo model library by (Wilensky and Rand 2015)
• Netlogo model library by (Romanowska, Wren, and Crabtree 2021)

Learning goals per practicum

Practicum 1

• Overview: Introduction to the practicum.
• Setup: NetLogo and Python Mesa environment setup.
• Coding Style: Study coding style differences in NetLogo and Python, focusing on the basic models (and fire model).
• Basics: Initialize and investigate basic setups.

Practicum 2

• Dispersal Model (NetLogo): Introduction to the dispersal model in NetLogo.
• Python Equivalent: Coding up a Python equivalent of the dispersal model.
• Python Challenge: Can we adjust Mesa to work with a custom map?

Practicum 3

• Challenge Review: Review of the previous challenge.
• El Faro Model: Introduction to the El Faro model.
• Data Handling: Collecting and plotting data in Mesa.

Practicum 4

• Part 1: Wolf-sheep model and Amphor model.
• Part 2: More advanced analyzing of data in Mesa.

Practicum 5

• Part 1: Possible slot for remaining matters and review.
• Part 2: Dedicated work session on your own model together.

Practicum 6

• Model Development: Continue working on your own model collaboratively.

Installation

Installation Section

Installation Guide Netlogo

You can download Netlogo from the official website: Netlogo Download. Just fill in your credentials and download the latest version of Netlogo.

Python, PyPi package Mesa, and installation

Installation guide python using anaconda + mesa

This installation I have tested on multiple machines. Feel free to deviate if you have different preferences for your python installation.

Install anaconda quick guide here.

Install Visual Studio Code (but feel free to use any other IDE you like, such as PyCharm, JupyterLab, etc.).

After installing anaconda, you can install mesa using the following command in your terminal:

conda create -n mesa-env python=3.11

conda activate mesa-env

pip install mesa[all]==3.2.0

pip install jupyter notebook scipy seaborn pandas numpy matplotlib ipykernel

python -c "import mesa; print(f'Mesa version: {mesa.__version__}')"

We will use Visual Studio Code which has a built-in jupyter notebook viewer. We will do that as the default. Do note that you need to “trust” the notebook or the model folder when you open it for the first time (otherwise you get issues activating your environment). When you run your notebook chunks, make sure you select the right kernel (mesa-env).

Some basic differences in coding style

Python

Basics

# This is a comment in Python - use # for single line comments
print("Hello, World!")  # This prints a message to the console

# Variables - store data with descriptive names
my_variable = 42  # Integer (whole number)
name = "Agent"    # String (text)

# Lists - collections of items in square brackets
my_list = [1, 2, 3, 4]
random_item = random.choice(my_list)  # Pick random item from list

Set up agent for grid

# Import Mesa - the agent-based modeling framework
import mesa
from mesa.discrete_space import CellAgent, OrthogonalMooreGrid

# Define our agent class - inherits from CellAgent (built for grid movement)
class SimpleGridAgent(CellAgent):
    def __init__(self, model, cell):
        # Call parent class constructor - this sets up basic agent properties
        super().__init__(model)
        # Assign agent to a specific cell on the grid
        self.cell = cell

# Define our model class - this manages the simulation
class SimpleGridModel(mesa.Model):
    def __init__(self, width=20, height=20):
        # Call parent class constructor - sets up basic model
        super().__init__()
        # Create grid: (width, height), wraps around edges, uses model's randomizer
        self.grid = OrthogonalMooreGrid((width, height), torus=True, random=self.random)
        # Create one agent and place it randomly on the grid
        random_cell = self.random.choice(list(self.grid.all_cells.cells))
        SimpleGridAgent(self, random_cell)

Set up agent for continuous

# Import Mesa components for continuous (smooth) movement
import mesa
from mesa.experimental.continuous_space import ContinuousSpaceAgent, ContinuousSpace
import numpy as np  # For mathematical operations and arrays

# Agent that can move smoothly in any direction
class SimpleAgent(ContinuousSpaceAgent):
    def __init__(self, model, space, position=(0, 0), speed=1):
        # Call parent constructor - sets up continuous space agent
        super().__init__(space, model)
        # Position as numpy array for easy math operations
        self.position = np.array(position, dtype=float)
        # How fast agent moves each step
        self.speed = speed

        # Generate random direction (angle between 0 and 2π radians)
        angle = self.model.rng.uniform(0, 2 * np.pi)
        # Convert angle to direction vector (x, y components)
        self.direction = np.array([np.cos(angle), np.sin(angle)])

# Model for continuous space simulation
class SimpleModel(mesa.Model):
    def __init__(self, width=100, height=100):
        super().__init__()
        # Create continuous space: [[x_min, x_max], [y_min, y_max]]
        # torus=True means edges wrap around (like Pac-Man)
        self.space = ContinuousSpace([[0, width], [0, height]],
                                   torus=True, random=self.random)

        # Create agent at random position within the space bounds
        position = self.rng.random(2) * np.array([width, height])
        agent = SimpleAgent(self, self.space, position)
        # Add agent to model's agent collection
        self.agents.add(agent)

Grid movement

def step(self):
    # Get current position
    x, y = self.cell.coordinate
    w, h = self.model.grid.dimensions

    # Define possible moves: North, East, South, West
    moves = [
        (x, (y+1) % h),  # North note modulo (%) functions as a wrap-around for toroidal grid
        ((x+1) % w, y),  # East
        (x, (y-1) % h),  # South
        ((x-1) % w, y)   # West
    ]

    # Pick random direction and move there
    new_x, new_y = self.random.choice(moves)

    # Find the cell at new position
    for cell in self.model.grid.all_cells.cells:
        if cell.coordinate == (new_x, new_y):
            self.cell = cell
            break

# In the model
def step(self):
    self.agents.do("step")

Continuous movement

def step(self):
    """Agent's step method - called every simulation tick"""
    # Move forward in current direction
    # position + (direction_vector * speed) = new_position
    self.position += self.direction * self.speed

# In the model class
def step(self):
    """Model's step method - runs the simulation forward one tick"""
    # Tell all agents to perform their step() method
    self.agents.do("step")

Complete grid example

# Import Mesa components for grid-based modeling
import mesa
from mesa.discrete_space import CellAgent, OrthogonalMooreGrid
from mesa.visualization import SolaraViz, make_space_component

class SimpleGridAgent(CellAgent):
    """Agent that moves randomly on a discrete grid"""
    def __init__(self, model, cell):
        # Initialize parent CellAgent class
        super().__init__(model)
        # Assign agent to specific grid cell
        self.cell = cell

    def step(self):
        """Move to adjacent cell in cardinal direction (N, E, S, W)"""
        # Get current position coordinates
        x, y = self.cell.coordinate
        w, h = self.model.grid.dimensions  # Grid width and height

        # Define possible moves: North, East, South, West
        # Using modulo (%) for torus wrapping - edges connect to opposite side
        moves = [
            (x, (y+1) % h),  # North - move up, wrap to bottom if at top
            ((x+1) % w, y),  # East - move right, wrap to left if at right edge
            (x, (y-1) % h),  # South - move down, wrap to top if at bottom
            ((x-1) % w, y)   # West - move left, wrap to right if at left edge
        ]

        # Pick random direction from available moves
        new_x, new_y = self.random.choice(moves)

        # Find the cell object at the new position
        # (Grid stores cells, we need the cell object, not just coordinates)
        for cell in self.model.grid.all_cells.cells:
            if cell.coordinate == (new_x, new_y):
                self.cell = cell  # Move agent to new cell
                break  # Stop searching once found

class SimpleGridModel(mesa.Model):
    """Model with discrete grid and one moving agent"""
    def __init__(self, width=20, height=20):
        super().__init__()
        # Create orthogonal grid (4-connected, not diagonal)
        # torus=True means edges wrap around
        self.grid = OrthogonalMooreGrid((width, height), torus=True, random=self.random)

        # Create one agent and place it randomly
        random_cell = self.random.choice(list(self.grid.all_cells.cells))
        SimpleGridAgent(self, random_cell)

    def step(self):
        """Run one simulation step - all agents act"""
        self.agents.do("step")  # Tell all agents to perform their step

# Visualization function - defines how agents look on screen
def agent_portrayal(agent):
    """Draw agent as red circle"""
    return {"color": "#FF0000", "size": 0.5}  # Red color, small size

# Create model and set up visualization
model = SimpleGridModel()
page = SolaraViz(model, [make_space_component(agent_portrayal=agent_portrayal)],
                name="Grid Agent")

Complete continuous example

# Import all necessary libraries
import numpy as np  # For mathematical operations
import mesa         # Main ABM framework
from mesa.experimental.continuous_space import ContinuousSpaceAgent, ContinuousSpace
from mesa.visualization import SolaraViz, make_space_component
from matplotlib.markers import MarkerStyle  # For arrow visualization

class SimpleAgent(ContinuousSpaceAgent):
    """An agent that moves smoothly through continuous space"""
    def __init__(self, model, space, position=(0, 0), speed=1):
        # Initialize parent class
        super().__init__(space, model)
        # Store position as numpy array for vector math
        self.position = np.array(position, dtype=float)
        self.speed = speed

        # Generate random starting direction
        angle = self.model.rng.uniform(0, 2 * np.pi)  # Random angle in radians
        # Convert angle to unit vector (direction with length 1)
        self.direction = np.array([np.cos(angle), np.sin(angle)])

    def step(self):
        """Move agent forward in its current direction"""
        # Vector addition: new_position = old_position + (direction * speed)
        self.position += self.direction * self.speed

class SimpleModel(mesa.Model):
    """Model containing agents in continuous space"""
    def __init__(self, width=100, height=100):
        super().__init__()
        # Create 2D continuous space with specified dimensions
        self.space = ContinuousSpace([[0, width], [0, height]],
                                   torus=True, random=self.random)

        # Create single agent at random starting position
        position = self.rng.random(2) * np.array([width, height])
        agent = SimpleAgent(self, self.space, position)
        self.agents.add(agent)

    def step(self):
        """Advance simulation by one time step"""
        self.agents.do("step")

# Visualization function - defines how agents appear
def agent_draw(agent):
    """Draw agent as arrow pointing in movement direction"""
    # Calculate angle from direction vector
    angle_rad = np.arctan2(agent.direction[1], agent.direction[0])  # y, x for correct angle
    angle_deg = np.degrees(angle_rad)  # Convert to degrees for marker

    # Create arrow marker and rotate it to show direction
    marker = MarkerStyle(marker='>')  # Right-pointing arrow
    marker._transform = marker.get_transform().rotate_deg(angle_deg)

    # Return visualization properties
    return {"color": "blue", "size": 15, "marker": marker}

# Create and run the simulation
model = SimpleModel()
page = SolaraViz(model, [make_space_component(agent_portrayal=agent_draw,
                        backend="matplotlib")], name="Continuous Agent")

NetLogo

Basics

;; This is a comment in NetLogo - use semicolons
print "Hello, World!"  ;; This prints a message when run in the command center

;; Variables - NetLogo has different ways to create variables
let my-variable 42     ;; Local variable (exists only in this procedure)
set name "Agent"       ;; Set a global or existing variable

;; Lists - collections of items in square brackets
let my-list [1 2 3 4]
let random-item one-of my-list  ;; Pick random item from list

Set up agent for grid

to setup
  clear-all              ;; Clear the world and reset everything
  color-grid            ;; Call our custom procedure to color patches
  create-turtles 1 [    ;; Create 1 turtle (agent)
    set size 1.5                          ;; Make turtle visible
    setxy random-pxcor random-pycor       ;; Random patch coordinates (integers)
    set color green                       ;; Color the turtle green
  ]
  reset-ticks           ;; Reset the tick counter to 0
end

to color-grid
  ask patches [         ;; Tell every patch to do the following:
    ;; Create checkerboard pattern: if sum of coordinates is even, color white
    if (pxcor + pycor) mod 2 = 0 [ set pcolor white ]
    ;; Patches default to black, so odd sums stay black
  ]
end

Set up agent for continuous

to setup
  clear-all                    ;; Clear everything and start fresh
  create-turtles 1 [          ;; Create 1 turtle (agent)
    set size 3                              ;; Make turtle bigger and visible
    setxy random-xcor random-ycor           ;; Random float coordinates anywhere
    set heading random 360                  ;; Random direction (0-359 degrees)
  ]
  reset-ticks                 ;; Reset simulation time to 0
end

Grid movement

to go
  ask turtles [                          ;; Tell all turtles to:
    let direction one-of [0 90 180 270]    ;; Pick random cardinal direction
    ;; 0=North, 90=East, 180=South, 270=West
    set heading direction                  ;; Face that direction
    fd 1                                   ;; Move forward 1 patch
  ]
  tick                                   ;; Advance time by 1 tick
end

Continuous movement

to go
  ask turtles [                    ;; Tell all turtles to:
    forward 1                        ;; Move forward 1 unit in current direction
    ;; Turtle keeps same heading, just moves forward smoothly
  ]
  tick                             ;; Advance simulation time by 1 tick
end

Complete grid example

;; Complete NetLogo model for grid-based random walk

to setup
  clear-all                    ;; Reset the world
  color-grid                  ;; Create checkerboard pattern
  create-turtles 1 [          ;; Create single agent
    set size 1.5                        ;; Make agent visible
    setxy random-pxcor random-pycor     ;; Place on random patch (grid cell)
    set color green                     ;; Color it green
  ]
  reset-ticks                 ;; Start time counter at 0
end

to color-grid
  ask patches [               ;; For every patch (grid cell):
    ;; Create alternating pattern based on coordinate sum
    if (pxcor + pycor) mod 2 = 0 [
      set pcolor white        ;; Even sum = white patch
    ]
    ;; Odd sum patches stay default black
  ]
end

to go
  ask turtles [                          ;; Each turtle does:
    let direction one-of [0 90 180 270]    ;; Pick random cardinal direction
    set heading direction                  ;; Turn to face that direction
    fd 1                                   ;; Move forward 1 patch
  ]
  tick                                   ;; Increment time counter
end

Complete continuous example

;; Complete NetLogo model for continuous space movement

to setup
  clear-all                    ;; Reset simulation
  create-turtles 1 [          ;; Create single agent
    set size 3                          ;; Make turtle large and visible
    setxy random-xcor random-ycor       ;; Random position (any x,y coordinates)
    set heading random 360              ;; Random initial direction (0-359 degrees)
  ]
  reset-ticks                 ;; Start time at 0
end

to go
  ask turtles [               ;; Each turtle:
    forward 1                   ;; Move forward 1 unit in current heading
    ;; Agent moves smoothly - can be at any decimal coordinates like (15.7, 23.2)
  ]
  tick                        ;; Advance time by 1 step
end

Model library for this course

Note we have stored the models in a .rar file. You can download the models and extract them using a program like WinRAR or 7-Zip.

Basic models

• Basic Grid, Continuous, Network Model Folder Python
• Basic Grid, Continuous, Network Model Folder Netlogo

Dispersal model and DIY

• Download Model Folder Netlogo

We will not actually give you the python version of the model, because we are going to build it together on the basis of the netlogo model and the chapter (see #slides-key-literature).

Criticality Fire model

• Download Criticality Fire Model Folder Python
• Download Criticality Fire Model Folder Netlogo

Flocking model

• Flocking Model Folder Python
• Flocking Model Folder Netlogo

El Farol Model

• El Farol Model Folder Python
• El Farol Model Folder Netlogo

Amphor Model

• TODO Python
• Amphor Model Folder Netlogo

Wolf-Sheep Model

• Wolf-Sheep Model Folder Python
• Wolf-Sheep Folder Netlogo

Slides and exercises

Slides practicum 1

Open slides in new window

Slides Practicum 2

Open slides in new window

Slides Practicum 3

Open slides in new window

Slides Practicum 4

Open slides in new window

Slides Practicum 5

Open slides in new window

Slides Practicum 6

Open slides in new window

Key background literature for the models

Materials for basic models

For understanding the structure of the python mesa base models, you can can have a look at the their tutorial by (Kazil, Masad, and Crooks 2020).

For Netlogo: Chapter 1 (Romanowska, Wren, and Crabtree 2021)

This book chapter goes into the some basics of netlogo that is helpful for getting started with the base models.

Download PDF

Book chapter about dispersal model

Chapter 1 (Romanowska, Wren, and Crabtree 2021)

This book chapter goes into the dispersal model

Download PDF

Book chapter about fire model

Chapter 3 (Wilensky and Rand 2015)

This book chapter goes into the fire model

Download PDF

Book chapter about el farol model

Chapter 3 (Wilensky and Rand 2015)

This book chapter goes into the el farol model

Download PDF

Book chapters about flocking model

Chapter 2 (Smaldino 2023)

This book chapter goes into the flocking

Download PDF

Book chapters about wolf-sheep model

Chapter 4 (Wilensky and Rand 2015)

This book chapter goes into the wolf sheep model

Download PDF

Book chapter about amphor model

Chapter 6 (Romanowska, Wren, and Crabtree 2021)

This book chapter goes into the amphor model

Download PDF

Inspiration section

Click here for inspiration

Additional Multimedia Resources

• Santa Fe Complexity Podcast: The physics of collectives
• BJKS podcast: Paul Smaldino on ABM Modeling of Social Behavior
• Braininspired podcast: David Krakauer on how to think like a complexity scientist
• Interacting Minds Seminar: Marieke Woensdregt on ABM and language learning
• Carlos Gershenson on the Slower is Faster Effect

Research papers on modeling or patterns ripe for ABM modeling

• “An agent-based model of citation behavior” (Chacko et al. 2025) (download PDF)
• “Evolving general cooperation with a Bayesian theory of mind” (Kleiman-Weiner et al. 2025) (download PDF)
• “Evolution of foraging behaviour induces variable complexity-stability relationships in mutualist-exploiter-predator communities” (Wang et al. 2025) (download PDF)
• “Diffusion of complex contagions is shaped by a trade-off between reach and reinforcement” (Wan, Riedl, and Lazer 2025) (download PDF)
• “Reciprocity evolves more readily in competitive than cooperative socio-ecologies” (Romano, Saral, and De Dreu 2025) (download PDF)
• “An evolutionary model of rhythmic accelerando in animal vocal signalling” (Jadoul et al. 2025) (download PDF)

References

Chacko, George, Minhyuk Park, Vikram Ramavarapu, Ananth Grama, Pablo Robles-Granda, and Tandy Warnow. 2025. “An Agent-based Model of Citation Behavior.” arXiv. https://doi.org/10.48550/arXiv.2503.06579.

Jadoul, Yannick, Taylor A. Hersh, Elias Fernández Domingos, Marco Gamba, Livio Favaro, and Andrea Ravignani. 2025. “An Evolutionary Model of Rhythmic Accelerando in Animal Vocal Signalling.” PLoS Computational Biology 21 (4): e1013011.

Kazil, Jackie, David Masad, and Andrew Crooks. 2020. “Utilizing Python for Agent-Based Modeling: The Mesa Framework.” In Social, Cultural, and Behavioral Modeling, edited by Robert Thomson, Halil Bisgin, Christopher Dancy, Ayaz Hyder, and Muhammad Hussain, 308–17. Cham: Springer International Publishing. https://doi.org/10.1007/978-3-030-61255-9_30.

Kleiman-Weiner, Max, Alejandro Vientós, David G. Rand, and Joshua B. Tenenbaum. 2025. “Evolving General Cooperation with a Bayesian Theory of Mind.” Proceedings of the National Academy of Sciences 122 (25): e2400993122. https://doi.org/10.1073/pnas.2400993122.

Romano, Angelo, Ali Seyhun Saral, and Carsten K. W. De Dreu. 2025. “Reciprocity Evolves More Readily in Competitive Than Cooperative Socio-Ecologies.” Proceedings of the Royal Society B: Biological Sciences 292 (2050): 20250973. https://doi.org/10.1098/rspb.2025.0973.

Romanowska, Iza, Colin D. Wren, and Stefani A. Crabtree. 2021. Agent-Based Modeling for Archaeology: Simulating the Complexity of Societies. The SFI Press Scholar Series.

Smaldino, Paul E. 2023. Modeling Social Behavior Princeton University Press. Princeton University Press.

Wan, Allison, Christoph Riedl, and David Lazer. 2025. “Diffusion of Complex Contagions Is Shaped by a Trade-Off Between Reach and Reinforcement.” Proceedings of the National Academy of Sciences 122 (28): e2422892122. https://doi.org/10.1073/pnas.2422892122.

Wang, Lin, Ting Wang, Xiao-Wei Zhang, Xiao-Fen Lin, Jia Li, Jin-Bao Liao, and Rui-Wu Wang. 2025. “Evolution of Foraging Behaviour Induces Variable Complexity-Stability Relationships in Mutualist-Exploiter-Predator Communities.” PLOS Computational Biology 21 (7): e1013245. https://doi.org/10.1371/journal.pcbi.1013245.

Wilensky, Uri, and W. Rand. 2015. An Introduction to Agent-Based Modeling. MIT Press.
